產品名稱：UHF-KF-2- 瀏覽次數：
- 榮譽出品：射頻同軸連接器
法蘭安裝終端連接器／Flange-mounted terminal connector
直式插座/Straight Socket
|
產品名稱/Product type |
適用電纜/Apply cable |
備注/Notes |
|
UHF-KF-2 |
|
UHF型母頭 |
主要技術特性 TECHNICAL CHARACTERISTICS
|
溫度范圍 Temp.range |
-40～+85°C |
|
特性阻抗 Impedance |
無恒定常數 Non-constant |
|
頻率范圍 Frequency Range |
DC～300 MHz |
|
工作電壓 Working Voltage |
750V max (有效值) |
|
耐 壓 Withstand Voltage |
2000V rms (海平面有效值) |
|
接觸電阻 Contact resistance |
內導體之間 Center Contact≤ 5 mΩ |
|
外導體之間 Outer Contact ≤ 5 mΩ | |
|
絕緣電阻 Insulation resistance |
≥ 5000 MΩ |
|
耐久性Durability(mating) |
≥500次（cycles） |
材料與涂覆 MATERIAL & PLATING
|
殼體 shell |
黃銅 brass |
鍍亮鎳 nickel plated |
|
插針 contact pin |
黃銅 brass |
鍍金或銀 gold or silver plated |
|
插孔 socket |
鈹青銅 beryllium |
鍍金或銀 gold or silver plated |
|
絕緣體 insulator |
聚四氟乙烯或聚乙烯 PTFE or PE |
|
|
壓接套 crimping suite |
銅合金 copper alloy |
鍍亮鎳 nickel plated |
|
O型密封件o-ring sealing |
硅橡膠 6146 silastic |
|
適用技術標準 APPLICABLE STANDARD
IEC 60169-12;
GB/T 15888.
